Ricoh MP CW2201 - Page 359

2. Remove the sensor bracket [A] ( x1).
3. Pull out the sensor bracket [A] release the clamp [B], and pull away the harness. ( x1).
4. Disconnect the paper entrance sensor (Right) [A] ( x1, x4).
5. Remove the exit sensor [B] ( x1, x4).
Roll Units
353
