Ricoh MP CW2201 Service Manual

6. Release the FFCs (backward) from the bottom of the HRB. ( x2)
7. Take two caps of the accessories of the new print head.
8. Push the two white projections of the black print head to release the air from the head
tanks (K1) and (K2).
Carriage Unit
433

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
