Ricoh MP CW2201 Service Manual

14. Slightly pull up the black print head to be removed to release it from the guide rod
backward. Then place it on several sheets of paper.
15. Check that the ink does not spill on the paper beneath the removed print head. If it spills,
change the paper.
16. Release the FFCs from the removed print head.
• Attach the released FFCs to the new print head.
4. Replacement and Adjustment
436

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
