Counter Reset/Ink Filling
1. Check that the new ink collector tank is attached.
2. Open the ink cartridge cover, remove the customer's ink cartridge, and attach the
new ink cartridge.
• Keep the ink-cartridge cover open.
3. Set the main power switch to ON. If an error is displayed on the operation panel,
ignore it.
• If SC282-XX (air detection frequency error) is displayed, ignore it.
4. Enter SP mode
5. Select SP2-400-001 (Carriage Unit Replacement NV Clear), set the values shown
below depending on the replaced print head unit, and execute the SP.
For Enter
Black and color print heads 0
Black print head only 1
Color print head only 2
6. Exit SP mode and set the main power switch to OFF.
7. Close the ink-cartridge cover.
8. Set the main power switch to ON (the initial filling sequence will begin
automatically).
• The initial filling sequence requires about 15 minutes.
• When the initial filling sequence ends, the machine beeps.
• Do not use the operation panel nor open the cover during the initial filling sequence.
9. When the initial filling sequence completes, print the nozzle check pattern and check
that every nozzle is firing. (Nozzle Check Pattern Print)
• If the print head unit is uncapped during replacing, some nozzle may not be firing. In
such a case, recover it by cleaning or flushing the print heads. (Clean Print Heads, Flush
Print Heads)
Carriage Unit
463
