• After configuring the exit stacker for one of these modes, always check the ends of the rods to
confirm that they are set correctly.
Easy Installation of Exit Stacker
The exit stacker is assembled as below at shipping from the factory.
Exit stacker installation is easier than MP CW2200.
Right Side
The optical cloth holder [1] attached to the right side of the scanner unit holds the accessory optical
cloth [2], which can be used to clean the exposure glass. The scanner stand [3] holds the scanner
unit above the main unit. The ink collector tank cover [4] can be opened and closed for insertion
and removal of the ink collector tank [5].
1. Product Information
46
