Ricoh MP CW2201

SC202-49 D Head Tanks 6 and 7: Ink Level Feeler Error 1
No air release (ink entry, etc.) Feeler did not release, even when air release
valve was pressed manually. Even at negative pressure, the feeler against the
wall of the tank did not detect any change.
• Feeler cannot be detected because it is out of position (loose, broken,
defective, or blocked by an obstruction)
• Air release solenoid blocked
• Maintenance unit defective
• Print head ink tank defective
• Air release solenoid defective
SC202-51 D Head Tank 1: Ink Level Feeler Error 2
SC202-52 D Head Tank 2: Ink Level Feeler Error 2
SC202-53 D Head Tank 3: Ink Level Feeler Error 2
SC202-54 D Head Tank 4: Ink Level Feeler Error 2
SC202-55 D Head Tank 5: Ink Level Feeler Error 2
SC202-56 D Head Tank 6: Ink Level Feeler Error 2
SC202-57 D Head Tank 7: Ink Level Feeler Error 2
SC202-58 D Head Tanks 3 and 4: Ink Level Feeler Error 2
SC202-59 D Head Tanks 6 and 7: Ink Level Feeler Error 2
While ink tank was under negative pressure, ink level sensor feeler was out of
position and caused the error. Air is releasing now but not previously.
• Dirty horizontal encoder strip
• Obstruction between feeler and side of the ink tank
SC202-61 D Head Tank 1: Ink Level Feeler Error 3
SC202-62 D Head Tank 2: Ink Level Feeler Error 3
SC202-63 D Head Tank 3: Ink Level Feeler Error 3
SC202-64 D Head Tank 4: Ink Level Feeler Error 3
SC202-65 D Head Tank 5: Ink Level Feeler Error 3
SC202-66 D Head Tank 6: Ink Level Feeler Error 3
SC200: Image Writing
665
