No. Component Function
1 Main Switch Switches the machine on/off.
2 Horizontal Motor Mounted at the left rear corner of the printer, the horizontal
motor alternately runs forward and reverse to drive the timing
belt that moves the carriage to the left and right during
printing. The operation of the motor is controlled by the
horizontal encoder strip stretched across the width of the
printer and threaded through the horizontal encoder sensor
on the right rear corner of the carriage unit. The sensor reads
this strip as the carriage moves from side to side and uses
these readings to control the operation of the motor.
3 Front Cover Track Switch A push switch mounted on the left post of the main machine
that detects when the pin on the left end of the front cover is
mounted correctly in its track.
4 Operation panel The intuitive 10.1 inch operation panel eliminate all hardware
key from the panel.
5 Paper transport fan The large fan mounted below the perforated platen plates.
This fan creates the suction that holds the paper on the paper
path.
6 Front Cover Switch: Right One of two safety switches that disable the machine when the
front cover is opened.
7 Cutter HP Switch Detects when the cutter has arrived at the home position on
the right and switches the cutter motor off.
8 Exit Sensor Located at the paper exit of the main machine, detects the
leading and trailing edges of the paper. Signals an error if
the paper fails to arrive or leave the sensor location within the
prescribed time.
9 Paper Exit Guide Switch Detects when the exit guide plate on the front of the machine
is opened and closed.
10 Cutter Return Switch Detects when the cutter has arrived at the left side of the
machine after cutting. Reverses the cutter motor, which moves
the cutter back to the home position on the right side of the
machine.
6. Troubleshooting
746
