No. Component Function
11 Cutter Motor Drives the cutter to the left and right across the paper path
when cutting paper. The cutter cuts as it moves from right to
left. When the cutter reaches the left side, the cutter return
sensor reverses the motor. A guide lever falls into a lower
track that lowers the cutter so that it passes under the paper
on its return to the home position on the right.
12 Vertical Encoder HP
Sensor
Mounted opposite and lower than the vertical encoder sensor
on the left side of the machine, this sensor also reads the code
on the rim of the vertical encoder wheel, and detects when
the wheel reaches the home position and switches off the
vertical motor. This sets the encoder wheel at the start position
for every job.
13 Vertical Motor The vertical motor drives the paper feed rollers and exit
rollers in the main machine. The operation of this motor is
controlled by the vertical encoder sensor and vertical HP
sensor which read the encoded rim of the vertical encoder
wheel.
14 Vertical Encoder Sensor The rim of the vertical encoder wheel on the left side of the
machine is centered in the gap of this sensor. The sensor
reads the code on the rim of the vertical encoder wheel as it
rotates, to control the operation of the vertical motor during
paper feed.
Electrical Components
747
