Ricoh MP CW2201 Service Manual

LED Color LED Status
LED106
Yellow-
green
Normal: Flash
Abnormal: Not lit
LED107 Yellow
Standby: Flash
Operation: Lit
LED108 Yellow
Standby: Flash
Operation: Lit
LED109 Red
5VX input: Lit
Others: Not lit
LED111 Green
3.3V input: Lit
Others: Not lit
Fuse
Name Output terminal Capacity Voltage Type Part No.
FU1
CN215
CN216
76V 5A 5.1V Operation panel 11071302
FU2 - 250V T6.3A 24V BiCU 11071374
FU3 CN203 250V T6.3A 24V
Main scan and sub
scan motor
11071374
FU4 CN214 72V 0.5A 5V NMB 11071211
FU5 - 250V T2A 5V Sensors 11071362
FU6 - 72V 2.5A 5V BiCU 11071219
FU7
CN208 to
CN211
250V T2.5A 37V HRB 11071226
FU8 CN214 250V T2A 24V HVP 11071362
FU9 CN210 72V 2.5A 5.1V HRB 11071219
FU10 CN218 76V 1.6A 5.1V MKB 11071127
FU11 CN213 72V 4A 24V Intake fan 11071107
6. Troubleshooting
766
