Ricoh MP CW2201 Service Manual

Item 5K m 10K m 20K m 30K m EM
1 Exposure Glass I, C
2 Original Width Sensors C
3 Original Feed Roller C
4 Original Exit Roller C
5 White Plate I, C
6 CIS Lens C
Horizontal Unit
7 Black Print Head Unit (K1, K2) R
8 Color Print Head Unit (C, YM) R
9 Horizontal Encoder C
10 DRESS Sensor C
Maintenance Unit
11 Maintenance Unit R
Waste Ink Collection
12 Ink Collector Tank R
13 Right Ink Sump I
14 Left Ink Sump R
Ink Supply
15 Ink Tube Guide C
Paper Feed
16 Platen C C
17 Paper Feed Rollers C
Vertical Unit
18 Vertical Encoder C
Auto Nozzle Check
2. Preventive Maintenance Tables
14
