Ricoh MP CW2201 Service Manual

Main SP Tables-3
SP3-XXX
3005 Head Gap Adjust Mj4-20KHz
1 Adjusted Value on Fitting A [-400 to 400 / 0 / 1dot]
3 Adjusted Value on Fitting B
5 Adjusted Value on Fitting C
8 Adjusted Value on Fitting D
51 By-pass: Normal-Thick A [-400 to 400 / 0 / 1dot]
53 By-pass: Normal-Thick B
55 By-pass: Normal-Thick C
58 By-pass: Normal-Thick D
101 Paper Supply 1: Normal-
Thick A
[-400 to 400 / 0 / 1dot]
103 Paper Supply 1: Normal-
Thick B
105 Paper Supply 1: Normal-
Thick C
108 Paper Supply 1: Normal-
Thick D
151 Paper Supply 2: Normal-
Thick A
153 Paper Supply 2: Normal-
Thick B
155 Paper Supply 2: Normal-
Thick C
158 Paper Supply 2: Normal-
Thick D
3. SP Mode Tables
60
