IP Fundamentals
P31003-H3550-S403-4-7620, 02/05
13-6 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
ip_.fm
Network analysis
13.3 Network analysis
The Network Analysis service module is used to check whether the customer’s communication
network is suitable for business-over-IP solutions from Siemens AG (HiPath 3000, HiPath
4000, HiPath 5000, etc.). The assessment is carried out on the basis of parameters preset by
the products. The customer receives a final report in which the network structure and operating
parameters (percentage utilization, delay, jitter) are documented.
Information can be found on the HiPath Network Analysis home page: https://netinfo.icn.sie-
mens.de/es/products/prod_netzwerk_analyse_v2/product/home_page.
Customer benefits and cost-effectiveness
● Preparation of the network for future applications (VoIP)
● Determination of current traffic volume and percentage utilization, baselining
● Decision-making assistance for the introduction of VoIP solutions
Network analysis performance specification
● Examination of the suitability of customer networks for Siemens AG Voice-over-IP solu-
tions
● Recording of relevant parameters over a predefined test time
● Assessment on the basis of product specifications
● Interpretation of test results with suggestions of further measures
● Final report with recommendations
Configuration notes
For use when planning Siemens AG Voice-over-IP solutions
For use only in SNMP-based IP data networks (routers, IP switches, hubs)
>
Network analysis must be performed before installation of the relevant systems and
applications to guarantee smooth operation in the customer network.
Network analysis determines the conditions under which the customer’s network is
suitable for HiPath 3000/5000. The result report is an integral component of the re-
quirement specifications in the HiPath 3000/5000 solution contract.
