Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-27
Boards for HiPath 3000
Central Boards
Figure
Figure 3-2 CBRC Board (S30810-Q2935-Z301)
>
Disconnecting the battery buffer by unplugging the X27 jumper is necessary only for
testing (module test at the factory). Disconnection does not necessarily delete the
customer database (CDB). To delete the CDB, use the reset switch.
2
X27
X5
2
X11 X6
X8 O bus
X14
CMA
X13
CMS
X17
IMODN
X15 X16
X12
LIM
EVM
X32
X18
2
X3
X20
X19
MPPI/
EXMR
MMC
4 x T/RReset/reload
switch
RUN LED
LAN connector, 8-pin RJ45 jack
V.24 interface, 9-pin
SUB-D plug
2 x S
0
,
RJ45
jacks
X9
1
X1
8 x U
P0/E
1
