boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-119
Boards for HiPath 3000
Peripheral Boards
3.3.7 IVMP8 (not for U.S.), IVMP8R (not for U.S)
Introduction
The following boards are used for the integrated voice mail functionality in HiPath Xpressions
Compact in V1.2 and later:
● IVMP8 (Integrated Voice Mail Point) S30122-Q7379-X100 - for HiPath 3350 (wall housing)
● IVMP8R (Integrated Voice Mail Point Rack) S30122-K7379-Z100 - for HiPath 3300 (19-
inch housing)
Music on Hold can be used in V4.0 SMR-7 or later and announcements in V5.0 or later.
In addition, the boards have an Ethernet (10/100BaseT) interface which can be used for HiPath
Xpressions Compact administration (fast APS transfer, backup and restore activities).
For detailed information on HiPath Xpressions Compact, startup and administration, see the
manual for the product (see Section 1.6, “Information on the Intranet”: Electronic Documenta-
tion on Com ESY Products).
>
Only one IVMP8 or IVMP8R may be installed per system.
Slot 5 can only be used for the IVMP8 board in the HiPath 3350 (wall housing).
>
HiPath Xpressions Compact supports a central voice mail functionality in a HiPath
3000/5000 network. All stations can use the central voice mail server.
HiPath Xpressions Compact cannot be used as a central announcement device in a
network.
