Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-219
Boards for HiPath 3000
Peripheral Boards
Table 3-98 STMD8 - Assignment (SUXx8) (For U.S. Only)
#
a-Wire
(Tip)
b-Wire
(Ring)
SU connector
STMD8 CHAMP jack, MDF Notes
Backplane: Xx8
1
wht/blu 19 1Ra
Port 1
11 Receive –
blu/wht 39 1Rb 26 1 Receive +
2
wht/ora 38 1Sa 2 1 Transmit –
ora/wht 48 1Sb 27 1 Transmit +
3
wht/grn 27 2Ra
Port 2
32 Receive –
grn/wht 47 2Rb 28 2 Receive +
4
wht/brn 16 2Sa 4 2 Transmit –
brn/wht 46 2Sb 29 2 Transmit +
5
wht/gry 05 3Ra
Port 3
53 Receive –
gry/wht 45 3Rb 30 3 Receive +
6
red/blu 14 3Sa 6 3 Transmit –
blu/red 44 3Sb 31 3 Transmit +
7
red/ora 23 4Ra
Port 4
74 Receive –
ora/red 43 4Rb 32 4 Receive +
8
red/grn 32 4Sa 8 4 Transmit –
grn/red 42 4Sb 33 4 Transmit +
9
red/brn 11 5Ra
Port 5
95 Receive –
brn/red 31 5Rb 34 5 Receive +
10
red/gry 02 5Sa 10 5 Transmit –
gry/red 22 5Sb 35 5 Transmit +
11
blk/blu 13 6Ra
Port 6
11 6 Receive –
blu/blk 33 6Rb 36 6 Receive +
12
blk/ora 04 6Sa 12 6 Transmit –
ora/blk 24 6Sb 37 6 Transmit +
13
blk/grn 15 7Ra
Port 7
13 7 Receive –
grn/blk 35 7Rb 38 7 Receive +
14
blk/brn 06 7Sa 14 7 Transmit –
brn/blk 26 7Sb 39 7 Transmit +
15
blk/gry 17 8Ra
Port 8
15 8 Receive –
gry/blk 37 8Rb 40 8 Receive +
16
yel/blu 08 8Sa 16 8 Transmit –
blu/yel 28 8Sb 41 8 Transmit +
No other wires used.
