11.3 System Configuration
The following table indicates the maximum possible system configuration parameters for Hi-
Path Cordless Office. It also shows when
● CMA or CMS is necessary
● analog trunk access is possible.
Table 11-1 HiPath Cordless Office - System Configuration for HiPath 3000 V5.0
System
Max. no.
Clock modules
Maximum number of base sta-
tions BS with connection via
1xU
P0/E
Simultaneous
calls per BS
Max. no.
MTs
Analog
trunk access
to system
SLC16
SLC16N
SLCN
BS3/1
BS3/S
BS2/2 BS3/3
BS4
BS3/1
BS3/S
BS2/2 BS3/3
BS4
HiPath 3350
HiPath 3300
–––CMS– 1 – – – –2––– 8 No
–––CMA– 1 – – – –4––– 8 Yes
–––CMA3 – – – 3 4–––4 16 Yes
HiPath 3550
HiPath 3500
–––CMS– 1 – – – –2––– 8 No
–––CMA– 1 – – – –4––– 8 Yes
–––CMA7 – – – 7 4–––4 32 Yes
HiPath 3550 1 1 – CMS 16 – 8 8 16 4 – 8 12 12 64 Yes
HiPath 3750
HiPath 3700
4 4 – CMS 64 – 32 32 64 4 – 8 12 12
250 (with
4 SLC16/
SLC16N)
1
1 Up to 128 handsets are possible at an SLC16 or SLC16N.
Yes
HiPath 3800 – – 4 CMS 64 – 32 32 64 4 – 8 12 12
250 (with
4 SLCN)
2
2 Up to 128 MTs are possible at an SLCN.
Yes
Explanations:
● BS2/2 (S30807-H5471-X200) is a base station that supports a maximum of 8 calls when connected using
two U
P0/E
interfaces.
● BS3/1 (S30807-H5482-X): is a base station that supports a maximum of 4 calls.
● BS3/3 (S30807-H5485-X): is a base station that supports a maximum of 12 calls when connected using
three U
P0/E
interfaces.
● BS3/S (X30807-X5482-X100): The BS3/S single-cell base station guarantees the operation of a maximum
of one base station on the U
P0/E
interfaces of the central board. It is not possible to operate additional
base stations.
● BS4 (S30807-U5491-X): is a base station that supports a maximum of 12 calls when connected using
three U
P0/E
interfaces. In the case of a direct connection, it is only permitted to make the connection via
one U
P0/E
interface. The B channels in the base station BS4 require a license (see Chapter 8).
