Central Boards
● Two LEDs for displaying the LAN interface status:
–LED1:
– Green = 100 Mbps online (link)
– Yellow = 10 Mbps online (link)
– Flashing = active
– LED2 (green):
– On = full-duplex (FDX)
– Off = half-duplex
Diagram of CBSAP board
Figure 3-4 CBSAP Board (S30810-Q2314-X)
IMODN
LIMS
CMS
MPPI
MMC
