Boards for HiPath 3000

P31003-H3550-S403-4-7620, 02/05

3-38 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual

boards.fm

Central Boards

V.24 interface assignment

LAN connector assignment via LIMS

Table 3-19 CBSAP - V.24 Interface Assignment (SUB-D Plug)

X50/X51, Pin Signal Description

1 DCD Data carrier detect (not used)

2 RxD Receive data

3 TxD Transmit data

4 DTR Data terminal ready (not used)

50VGround

6 DSR Data send ready (not used)

7 RTS Request to send

8 CTS Clear to send

9 RI Ring indicator (not used)

Table 3-20 CBSAP - LAN Connector Assignment (RJ45 Jack)

Pin Signal Description

1 Tx + Transmit +

2 Tx – Transmit –

3Rx+Receive+

4 – Not used

5 – Not used

6Rx–Receive–

7 – Not used

8 – Not used
