Service
P31003-H3550-S403-4-7620, 02/05
12-24 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
service.fm
Guided Maintenance
● MPPI, UAM (only with HiPath 3550, HiPath 3350) or UAMR (only with HiPath 3500, HiPath
3300)
The availability of one of these Announcement and Music Modules is displayed as
“Option 5”.
The ALUM4 module cannot be displayed.
12.3.1.1.2 Power Supplies
12.3.1.1.3 Peripheral Boards
Viewing peripheral board status
You can use HiPath 3000 Manager E or Assistant T to view the status of all peripheral boards.
Display is limited to the following statuses per board:
● Board not inserted
● Board defective (not loaded)
● Board disabled
● Board enabled (active)
● Board busy (at least one station or line from this board is disconnected, is being called, or
is busy).
Table 12-3 Power Supply Status Displays
Board Status Display
HiPath 3800
LUNA2 The LED displays the operating status (on or off).
HiPath 3750, HiPath 3700
UPSM The LED displays the operating status (on or off).
HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300
PSUP The LED displays the 5-V output voltage.
UPSC-D, UPSC-DR ● A green LED displays the 5-V output voltage.
● A yellow LED displays the additional power of –48-V output volt-
age provided by an external power supply unit (EPSU2 or
EPSU2R).
