service.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
12-27
Service
Guided Maintenance
12.3.1.3 Recording Station Status
HiPath 3000 records the current status of each individual station in a table. You can use HiPath
3000 Manager E to view the station status, in which case the following information is provided.
Data Contents
Station name Name of the selected station
Slot, port Example: 7-1
Telephone model Example: optiPoint 500 advance
Telephone status Active or inactive
DID number External number of the selected station
Language Menu language of selected station
Connection status ● Inactive: The telephone is idle.
● Busy: The telephone is off the hook, but not yet di-
aled.
● Waiting: The telephone call is in the queue.
● Connected: The telephone is connected to a second
telephone with a trunk or a hunt group member.
● Holding: The telephone is on hold.
● Error: The connection cannot be established due to
an error (for example, invalid telephone number).
● Call: The telephone is called.
Connected to The number of the connected station or trunk
Forwarding status ● Off: No call forwarding activated.
● Internal: Call forwarding activated only for internal
calls.
● External: Call forwarding activated only for external
calls.
● All: Call forwarding activated for all calls.
Destination Number of call forwarding destination
