Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-100 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
3.3.4 HXGS3, HXGR3
Introduction
HXGS3 and HXGR3 are VoIP gateway boards (VoIP - Voice over IP), which provide the func-
tionality of HG 1500 in HiPath 3550, HiPath 3350 (HXGS3) and HiPath 3500, HiPath 3300
(HXGR3):
● Connection of a local LAN to the HiPath 3000 and connection with external LANs via the
ISDN and DSL interfaces of HiPath 3000.
● Support for the conventional functions of an ISDN and DSL router with the additional func-
tionality of a media gateway for the transfer of voice, fax and data.
● Forwarding of calls between IP-supported networks (LAN, intranet, Internet) and circuit-
switched networks (ISDN, PSTN).
Configuration is performed via Web-based management (WBM) which enables the administra-
tion of HG 1500 without any special software requirements.
For information on how to calculate the number of boards required for HG 1500, see
Section 10.6.4.
>
Up to three boards can be used in HiPath 3550 and HiPath 3500. To support this
maximum configuration, slot 10 (board in HiPath 3750 format) must remain free.
A maximum of one board is permitted in HiPath 3350 and HiPath 3300. Two
HG 1500 boards can be installed if PDM1 is not being used.
When using an HXGS3 in HiPath 3350, the lower supply unit PSUP must be re-
placed with UPSC-D.
It is not possible to operate an HXGS3 or HXGR3 and an LIM module simultaneously
in one system.
For information on configuration, refer to the HG 1500 Administration Manual.
7
Caution
When using an HXGS3 board in a HiPath 3550 or HiPath 3350, fan kit C39165-
A7021-D3 must be installed for thermal reasons (see Page 3-106).
