Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-8 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Overview
Overview of all board models used
Table 3-2 HiPath 3000 - Overview of All Boards Models Used
Board Part number Function
HiPath 3800
AMOM S30807-K5480-Xxxx Opto-electronic converter
CBSAP S30810-Q2314-X Central board
CMS S30807-Q6928-X Central board
DBSAP S30807-Q6722-X Central board
DIU2U S30810-Q2216-X Peripheral board (for U.S. only)
DIUN2 S30810-Q2196-X Peripheral board
IMODN S30807-Q6932-X100 Central board
IVMN8 S30122-H7688-X100 Peripheral board
IVMNL S30122-H7688-X Peripheral board
LIMS S30807-Q6721-X Central board
LUNA2 S30122-K7686-L1
S30122-K7686-M1
Central board
MMC S30122-X8002-X10 Central board
MPPI S30122-K7275-B Option
PBXXX S30810-Q6401-X Peripheral board
PDMX S30807-Q5697-X200 Option
PFT1/PFT4 S30777-Q539-X
S30777-Q540-X
Option (not for U.S.)
REALS S30807-Q6629-X Option
SLCN S30810-Q2193-X300 Peripheral board (not for U.S.)
SLMA S30810-Q2191-C300 Peripheral board
SLMA8 S30810-Q2191-C100 Peripheral board
SLMO2 S30810-Q2168-X10 Peripheral board
SLMO8 S30810-Q2168-X100 Peripheral board
STMD3 S30810-Q2217-X10
S30810-Q2217-X110
Peripheral board
STMI2 S30810-Q2316-X100 Peripheral board
TM2LP S30810-Q2159-Xxxx Peripheral board
TMC16 S30810-Q2485-X Peripheral board (for U.S. only)
TMDID S30810-Q2452-X Peripheral board (for U.S. only)
