Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-29
Boards for HiPath 3000
Central Boards
V.24 interface assignment
LAN connector assignment
Table 3-13 CBRC - V.24 Interface Assignment (SUB-D Plug)
X18, pin Signal Description
1–Not used
2 RxD A Receive data, channel A
3 TxD A Transmit data, channel A
4–Not used
50VGround
6–Not used
7 RTS A Request to send, channel A
8 CTS A Clear to send, channel A
9–Not used
Table 3-14 CBRC - LAN Connector Assignment (RJ45 Jack) via LIM
Pin Signal Description
1 Tx + Transmit +
2 Tx – Transmit –
3 Rx + Receive +
4–Not used
5–Not used
6 Rx – Receive –
7–Not used
8–Not used
