Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-277
Boards for HiPath 3000
Peripheral Boards
3.3.32 TMDID8 (for U.S. only)
Introduction
TMDID8 (Trunk Module Direct Inward Dialing) provides direct inward dialing from the central
office (CO) to HiPath 3750 and HiPath 3700.
The board has eight trunk circuits that connect to analog trunks.
The circuits can be set up for immediate start or wink start.
Switches and LEDs
Figure 3-112 TMDID8 (for U.S. only) (S30810-Q2507-X)
T4 T3 T2 T1
H1 H2 H3 H4 H5 H6 H7 H8
T8 T7 T6 T5
S4 S3
Trunk 7
Trunk 8
Tru nk 5
Tru nk 6
S2 S1
Tru nk 3
Tru nk 4
Trunk 1
Trunk 2
A
G
A
G
A
G
A
G
