power_calc.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
D-1
Identifying System Power Requirements
D Identifying System Power Requirements
This supplement specifies the power requirement of the boards and components of the HiPath
3000 systems. In addition, information is provided on the power requirement of the different
workpoint clients, key modules and adapters.
With this information,
● the individual system power requirement can be identified.
● every system configuration can be checked to see whether the nominal output of the power
supply unit is sufficient or whether an additional power supply may be needed.
>
The following values are for orientation only, and can vary depending on the traffic
flow.
Topic
HiPath 3800 Board Power Requirement, page D-2
HiPath 3750 and HiPath 3700 Board Power Requirement, page D-4
HiPath 3550 Board Power Requirement, page D-6
HiPath 3350 Board Power Requirement, page D-8
HiPath 3500 Board Power Requirement, page D-10
HiPath 3300 Board Power Requirement, page D-11
Workpoint Clients, Key Modules and Adapter Power Requirements, page D-12
Checking Whether the Output of a Power Supply Unit is Sufficient, page D-14
Identifying the Primary System Power Requirement, page D-17
>
To ensure that a system’s dynamic capacity limit is not exceeded, the configuration
can be tested using the project planning tool (Intranet: http://intranet.mch4.sie-
mens.de/syseng/perfeng/tools/hpt/index.htm).
