Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-329
Boards for HiPath 3000
Options
3.4.5 Announcement and Music Modules
Introduction
The HiPath 3000 systems use different modules or boards for playing announcements and mu-
sic on hold. For details on connecting these boards, refer to the manufacturer’s installation in-
structions.
Overview
7
Caution
Place the central control board on a flat surface before inserting a subboard. Other-
wise you may damage the board.
>
The following HiPath Xpressions Compact boards support music on hold in V4.0
SMR-7 or later and announcements in V5.0 or later:
● IVML8, IVML24 (HiPath 3750, HiPath 3700)
● IVMNL, IVMN8 (HiPath 3800)
● IVMP8 (not for U.S.), IVMP8R (not for U.S) (HiPath 3350, HiPath 3300)
● IVMS8, IVMS8R (HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300)
For detailed information on HiPath Xpressions Compact, startup and administration,
see the manual for the product (see Section 1.6, “Information on the Intranet”: Elec-
tronic Documentation on Com ESY Products).
Table 3-159 Announcement and Music Modules
Module/
Board
Part number Notes
EXM S30817-Q902-
B401
● Used in HiPath 3550 and HiPath 3350 (wall housing),
see Figure 3-142.
● Connected via cable to X4 connector on CBCC/CBCP.
EXMR S30122-K7403-Z
● Used in HiPath 3500 and HiPath 3300 (19-inch hous-
ing).
● Board installed directly on CBRC (X19 and X20).
● Connected via cable to Cinch jack on the front panel
(see Figure 3-143).
MPPI S30122-K7275-B ● Used in all HiPath 3000 systems
● Board installed directly on the central control board
(X19 and X20).
MPPI (not
for U.S.)
S30122-K5380-
X200
● Used in HiPath 3550 and HiPath 3350 (wall housing).
● Connected via cable to X4 connector on CBCC/CBCP.
