Installing HiPath 3000
Installing HiPath 3800
4.2.5 Installing Boards (Configuration Notes)
Introduction
The cabinet(s) are not supplied with pre-installed boards. Install the boards as described in the
following information.
4.2.5.1 Board Slots in the Basic and Expansion Cabinet
There are nine slots available in the basic cabinet BC (slots 1 to 5 and slots 7 to 10) and thirteen
in the expansion cabinet EC (slots 1 to 6 and slots 8 to 14) for peripheral boards.
The central control board CBSAP has a fixed slot (slot 6, only in the basic cabinet BC).
Depending on your requirements, up to three LUNA2 power supply units can be used in the
basic cabinet BC and up to four in the expansion cabinet EC.
7
Caution
Always wear an antistatic wristband when working on the system (especially when
handling boards).
7
Caution
● To ensure that the system operates without blocking, you must follow the instruc-
tions in Section 4.2.5.6 concerning PCM highway distribution.
● For thermal reasons the IVMNL board may only be installed in the basic cabinet.
