Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-204 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Figure 3-83 Wiring and Ranges for S
0
Bus Jacks
The connecting cord of the
ISDN telephone must not ex-
ceed
10 m in length.
To switch from external to inter-
nal S
0
operation, you must
cross the SR and SX wires be-
fore the first jack.
UAE
connector
Additional
power supply
230 V∼
Mini-Western
through-jack
(MW8 = 8-pin)
SR.1 Receive 5
SX.1 Transmit 3
SX.2 Transmit 6
SR.2 Receive 4
1st Mini-Western jack
(MW8 = 8-pin)
2nd to 8th Mini-Western jack
(MW8 = 8-pin)
100 Ω/0.25 W
Terminating resistor in last jack
System
S
0
1 to S
0
4
*
twisted
pair
8
1
765432
SX
SX SR
SR
* = Not crossed in TA-S
0
8
1
765432
8
1
765432
6
4
5
3
Maximum ranges:
System 3
12
8
Short bus: 150 m (492 ft.)
Long bus: 150 m (492 ft.)
20m
