IP Protocols and Port Numbers Used with HiPath 3000/5000 V5.0
HiPath FM Managed Systems
C.4 HiPath FM Managed Systems
Table C-4 HiPath FM Managed Systems - IP Protocols and Port Numbers Used
Service/
Application
Protocol Server
Port
Connect
With Oth-
er Servers
Possible Cli-
ents
Application Config-
urable
HTTP Com-
munication
Server, Web
Server, IIS
TCP 80, 280,
8085,
8080,
8170,
8888, 9170
– HiPath FM
Server
HiPath Server: for
communication
with systems to
be managed (port
8170 and 9170
added for detect-
ing TelasWeb),
PCM
No
HTTP Com-
munication
Server
TCP 80, 280,
8085,
8080,
8170,
8888, 9170
– HiPath FM Cli-
ent
Launch of detect-
ed http services
on systems to be
managed.
No
Telnet TCP 23 – HiPath FM
Server
Telnet integra-
tion of systems to
be managed
(HDMS 3.6)
Not required for
HTS 6.0 scenari-
os
No
SNMP Ser-
vice
UDP 161 – HiPath FM
Server
SNMP (Get/Set) No
“Ping” Man-
agement Ser-
vice
TCP 7 – HiPath FM
Server
IP status polling
of systems to be
managed
No
Element
Manager/Lo-
cal Manager
Depends
on the ap-
plication
used
Unknown – HiPath FM Cli-
ent
Launch of Ele-
ment Manager/
Local Manager of
customer system
(e.g. HiPath 4000
Assistant)
No
