Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-39
Installing HiPath 3000
Installing HiPath 3800
4.2.5.3 Mounting Connector Panels (if required)
The HiPath 3800 has various connection options for connecting the peripherals. If you intend
to use connector panels, mount the panels supplied as follows:
If Then
Connector panels
with RJ45 jacks
(see
Section 4.2.6.5)
Slot with
STMD3
Attach a connector panel with 8 RJ45 jacks (S30807-
Q6624-X) to the SIVAPAC connector on the back-
plane.
Slot with
SLCN
SLMA
SLMA8
SLMO2
SLMO8
TM2LP
TMC16
1
TMDID
1
Attach a connector panel with 24 RJ45 jacks (S30807-
Q6622-X) to the SIVAPAC connector on the back-
plane.
different or no as-
signment
Use filler panels to cover the backplane sections of
other boards and empty board slots.
For U.S. only:
Connector panels
with CHAMP jack
(see
Section 4.2.6.6)
Slot with
SLMA
SLMA8
SLMO2
SLMO8
STMD3
TM2LP
TMC16
1
TMDID
1
Attach a connector panel with CHAMP jacks (S30807-
Q6626-X) to the SIVAPAC connector on the back-
plane.
different or no as-
signment
Use filler panels to cover the backplane sections of
other boards and empty board slots.
