Siemens HiPath 3000 Service Manual

Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-40 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3800
Connector panels
with SIPAC 1 SU
connectors
(see
Section 4.2.6.7)
Slot with
SLCN
SLMA
SLMA8
SLMO2
SLMO8
STMD3
TM2LP
TMC16
1
TMDID
1
Plug a connector panel with SIPAC 1 SU connectors
(S30807-Q6631-X) into the SIVAPAC connector on
the backplane.
different or no as-
signment
Use filler panels to cover the backplane sections of
other boards and empty board slots.
1For U.S. only
