Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-170 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.4.3.4 Removing the System Housing Cover
Procedure
7
Warning
To prevent injuries, you must observe the following instructions for the removal and
attachment of the HiPath 3550 and HiPath 3350 housing cover.
Step Activity
1. Loosen the two screwed plugs on the housing cover with a slotted screw driver.
Hold the housing cover so that it does not fall.
