Siemens HiPath 3000 Service Manual

IP Protocols and Port Numbers Used with HiPath 3000/5000 V5.0
P31003-H3550-S403-4-7620, 02/05
C-12 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
portnos.fm
optiPoint 400, optiPoint 410, optiPoint 420, optiPoint 600 office
C.7 optiPoint 400, optiPoint 410, optiPoint 420, optiPoint 600 office
The workpoint clients support the flexible configuration (Flexible Port Numbering) of each TCP
and UDP port number, with the exception of:
● SNMP
● SNTP
● DNS
● WAP Push
● WAP Push secure
The following table shows the configurable port numbers and their output parameters. The Port
Base Number is used in some cases. The Port Base Number is the configurable port number,
not the port numbers derived from the Port Base Number.
Table C-7 optiPoint 400, optiPoint 410, optiPoint 420, optiPoint 600 office - Used IP Pro-
tocols and Port Numbers
Function Default port Note
UDP TCP
H.225.0 RAS Port Area 1720
H.225.0 Call Signaling Port Area 1720
H.245 TCP Channel Port Area (Lo-
cal)
1720
H.245 TCP Channel Port Area (Re-
mote)
Any
RTP Port Area (Local) 5010,
5012,
5014,
5016
The RTP port number is even-num-
bered. The RTCP port number is equiv-
alent to the RTP port number + 1.
5004 to 5007 are reserved by IANA.
RTP Port Area (Remote) Any
RTCP Port Area (Local) 5011,
5013,
5015,
5017
The RTP port number is even-num-
bered. The RTCP port number is equiv-
alent to the RTP port number + 1.
5004 to 5007 are reserved by IANA.
RTCP Port Area (Remote) Any
HTTP Hypertext Transport Protocol 8085
HTTPS Secure Hypertext Transport
Protocol
443
SNMP 161 Not configurable
