Workpoint Clients
optiPoint 500
10.2.1.7 Connection
Procedure: Connecting an optiPoint 500 Telephone
The first time the telephone is switched on,
● all LEDs light up briefly
● all LEDs on the add-on devices (AODs), if connected, light up briefly (AOD LEDs do not
necessarily flash at the same time as the LEDs on the telephone)
● all pixels on the display activate briefly.
Step Activity
1. Locate a free interface on the main distribution frame or internal distributor for con-
necting the telephone.
2. Connect the cable from the main distribution frame or internal distributor to the
wall outlet.
>
The maximum range for a standalone or host telephone without additional local pow-
er supply is approximately 1000 m (3280 feet) (for J-Y (ST) 2x2x0.6, ∅ 0.6 mm).
Perform the terminal test in Section 12.3.1.8 to determine whether a local power
supply is needed for additional power (for example, in host-client configurations or
for larger ranges).
3. Label the keys. You have the following options:
● by hand (in writing); label sheets come with each telephone.
● using a PC:
– with the “Key Labeling Tool” (requires MS Word
©
) which is contained on
the “Electronic Operating Instructions” CD.
– with the “Online Key Labeling Tool” which can be downloaded from http:/
/www.siemens.com/hipath (–> Downloads).
4. Prepare the telephone for connection:
● Connect the handset cord to the telephone (marked with symbol) and to the
handset.
● Do you plan to connect an add-on device? Refer to Section 10.2.2 on
page 10-16 for more information.
● Do you plan to connect an optiPoint adapter? Refer to Section 10.2.3 on
page 10-20 for more information.
5. Connect the line cord (marked on the telephone by a symbol).
optiPoint 500 telephones are shipped with a 6 m (20 ft.) line cord and an MW6
(RJ11) plug for connection to a modular telephone jack.
