Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-364 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Options
3.4.19 V.24 Cable
The V.24 cable is used, for example, for connecting a service PC to the V.24 interface on all
HiPath 3000 systems (V1.2 or later).
V.24 cable assignment
Figure 3-166 V.24 Cable Assignment (C30267-Z355-A25)
9-pin jack
DCD
RxD
TxD
DTR
DSR
RTS
CTS
GND
RI
1
2
3
4
6
7
8
5
9
Shield
Data Carrier Detect
Receive Data
Transmit Dat a
Data Terminal Ready
Data Send Ready
Request To Send
Clear To Send
Ground
Ring Indicator
DCD
RxD
TxD
DTR
DSR
RTS
CTS
GND
RI
1
2
3
4
6
7
8
5
9
9-pin jack
