Installing HiPath 3000
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.4.4.2 Selecting the Installation Site
Selecting a site
The customer usually has a preferred installation site in mind, for example an existing 19-inch
cabinet.
Make sure that the customer’s site meets the following guidelines:
● To guarantee sufficient system ventilation, allow a minimum of 10 cm clearance around the
housing.
● Do not expose the systems to direct sources of heat (for example sunlight and heaters).
● Do not expose the systems to extremely dusty environments.
● Avoid contact with chemicals.
● Take every precaution to prevent the formation of condensation on the system during op-
eration. Systems covered with condensation must be dried before being used.
● Observe the environmental conditions specified in Section 2.9.
You will find information on the design and dimensions in the following section:
● HiPath 3500 Section 2.2.2.6
● HiPath 3300 Section 2.2.2.7
4.4.4.2.1 For U.S. only: AC outlet
The AC connection must fulfill the requirements specified in Table 4-22.
Table 4-22 Electrical Connection Values (for U.S. only)
Nominal
voltage
Nominal voltage range Nominal Frequency
Range
Wall Outlet Configura-
tions
from to from to
120 V AC/
60 Hz
110 V AC 130 V AC 47 Hz 63 Hz NEMA 5-15, 2-pin, 3-
wire, earth
