inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-185
Installing HiPath 3000
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.4.3.11 Connecting Workpoint Clients
For information, see Chapter 10.
4.4.3.12 Making trunk connections
Refer to the following board descriptions for information:
● STLS2 (Not for U.S.), STLS4 (S
0
trunk connection)
● TS2, HiPath 3550 only (S
2M
trunk connection)
● TLA2 (Not for U.S.), TLA4 (Not for U.S.), TLA8 (Not for U.S.) (MSI)
● TMAMF (for selected countries only), HiPath 3550only
● TMGL4 (for U.S. only)
● TMQ4 (for U.S. only)
● TST1 (for U.S. only), HiPath 3550only
4.4.3.13 Performing a Visual Inspection
Before starting up the system, you must perform a visual inspection of the hardware, cables,
and the power supply. The visual inspection must be performed while the system is disconnect-
ed from the power supply.
7
Caution
Conduct the visual inspection only while the system is disconnected from the power
supply.
Always wear an antistatic wristband and observe the measures for protecting elec-
trostatically sensitive devices (see Page 1-9).
Step Activity Resources/Remarks Possible remedies
1. Compare the slots for the
installed boards with the
board assignment map.
Board assignment map Correct the board
configuration and no-
tify the sales depart-
ment.
2. Check the local line voltage. Digital multimeter
>
After finishing the visual inspection, you can begin starting up the system as de-
scribed in Chapter 5.
