4.2.5.7 Static Traffic Capacity
The static traffic capacity of the HiPath 3800 system can be determined as follows.
Table 4-5 HiPath 3800 - Static Traffic Capacity
HiPath 3800 Slots per PCM seg-
ment
Static traffic capac-
ity per PCM seg-
ment
Total static traffic
capacity of the
system
Single-cabinet sys-
tem
(see Page 4-45)
1 – 5 128 erlangs +
(128 erlangs
1
)
1 The basic cabinet provides two PCM highway bundles with 2 x 4 PCM highways each. DIUN2, DIU2U (for U.S. only),
IVMNL, IVMN8 and STMI2 use the PCM highways from bundle F. Thus there are an additional 128 time-division
multiplex channels available for slots 1 – 5 and for slots 7 – 10 for these boards in the basic cabinet. If HiPath 3800
is used as a two-cabinet system, a use of PCM highway bundle F is not possible.
512 erlangs
7 – 10 128 erlangs +
(128 erlangs
1
)
Two-cabinet system
(see Page 4-46)
1 – 5 128 erlangs
512 erlangs
7 – 10 128 erlangs
11 – 16 128 erlangs
18 – 24 128 erlangs
