Siemens HiPath 3000 - Figure 10-14 Example of a Host-Client Configuration

Workpoint Clients
P31003-H3550-S403-4-7620, 02/05
10-24 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
wclient.fm
optiPoint 500
Example of a host-client configuration
Figure 10-14 Example of a Host-Client Configuration
Local power sup-
ply (optional)
MW wall outlets
U
P0/E
to the system,
2-wire, up to 1000 m (3280 feet) U
P0/E
, 4-wire, up to 100 m (328 feet)
optiPoint 500 telephone with optiPoint
phone adapter
Client
Host
optiPoint 500 telephone
MW wall outlet
Local power supply
(optional)
