Siemens HiPath 3000 Service Manual

Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-74 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3800
4.2.7.3 Inserting External S
0
Patch Panel C39104-Z7001-B3
Structure
>
All incoming cables must be attached to the patch panel using cable ties.
Figure 4-43 S
0
Patch Panel C39104-Z7001-B3
3x8MW8 jacks
Necessary height units for 19-inch cabinet assembly: 1
(one height unit corresponds to approx. 1.7’’=43 mm)
