HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-49
Installing HiPath 3000
Installing HiPath 3800
4.2.6 Connecting the Cable to the Backplane
Connection options
Peripheral devices can be connected up to the HiPath 3800 in a number of different ways:
● SIVAPAC connector on the backplane for connecting the external main distribution frame
via CABLUs (prefabricated cabling units) or for connecting external patch panels (see
Section 4.2.6.4).
● Connector panels with RJ45 jacks for direct connection of peripherals (see
Section 4.2.6.5). The connector panels are clipped onto the SIVAPAC connectors on the
backplane.
● For U.S. Only: Connector panels with CHAMP jack for direct connection of peripherals (see
Section 4.2.6.6). The connector panels are clipped onto the SIVAPAC connectors on the
backplane.
● Connector panels each with two SIPAC 1 SU connectors for connecting the external mail
distribution frame MDFU-E or external patch panels using CABLUs (see Section 4.2.6.7).
The connector panels are clipped onto the SIVAPAC connectors on the backplane.
The type of connection used will be decided in consultation with the customer on conclusion of
the agreement. The cabinets will be delivered accordingly with or without clipped-on connector
panels.
>
All cables that leave the system cabinet must be attached to the metal back panel
using cable ties.
7
Danger
Be sure to connect the main protective earthing terminal on all system cabinets to
the grounding point of the electrical building installation before connecting up the pe-
ripherals (for example, potential equalization bus).
The system may only be started (connected to the power supply) if all system cabi-
nets are sealed at the rear with the connection and filler panels provided.
