Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-234 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
E&M interface type 1B or 5 (not for U.S.)
Figure 3-98 E&M Interface Type 1B or 5 (Not for U.S.)
2 3
1
5 6
4
2 3
1
CCT 1: S103
CCT 2: S203
CCT 3: S303
CCT 4: S403
E- 48 V
E
M
TIEL
S102
S202
S302
S402
E
E
M
Remote system/transmission
equipment with TIEL
2 3
1
5 6
4
2 3
1
CCT 1: S103
CCT 2: S203
CCT 3: S303
CCT 4: S403
S102
S202
S302
S402
- 48 V
