Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-257
Boards for HiPath 3000
Peripheral Boards
3.3.29 TMC16 (U.S. Only)
Introduction
The trunk module TMC16 (Trunk Module Central Office) connects up to 16 analog ground-start
or loop-start trunks with the HiPath 3800.
Front panel
Figure 3-107 TMC16 (for U.S. only) (S30810-Q2485-X) - Front Panel
>
To ensure sufficient shielding, provide the board with a shielding panel. For informa-
tion on mounting the shielding panel, see Section 4.2.5.2.
Two LEDs indicating the board status:
● LED (red)
● LED (green)
