Siemens HiPath 3000 - Figure 9-5 ECR with Built-In Batteries

Expanding and Upgrading HiPath 3000
P31003-H3550-S403-4-7620, 02/05
9-14 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
exup.fm
Expanding HiPath 3000
7
Caution
When storing an ECR equipped with batteries or if the ECR is inactive for a long pe-
riod of time, remove the battery fuse (6.3 A/T) in the front panel of the ECR.
When shipping an ECR with built-in batteries, the batteries must be removed before-
hand.
Figure 9-5 ECR With Built-In Batteries
1 2 43
