Siemens HiPath 3000 - Backplane of the Basic Cabinet; Figure 4-28 Hipath 3800 - Backplane (S30804-Q5392-X) of the Basic Cabinet

Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-50 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3800
4.2.6.1 Backplane of the Basic Cabinet
Figure 4-28 HiPath 3800 - Backplane (S30804-Q5392-X) of the Basic Cabinet
9 SIVAPAC connec-
tor for peripherals
68-pin DB68 mini-
jack (connection to
EC)
DC port
AC port
