Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-65
Installing HiPath 3000
Installing HiPath 3800
4.2.7.1 Using an External Main Distribution Frame MDFU-E S30805-U5283-X
For U.S. only:
Not more than 21 CABLUs per MDFU-E with one 16-TW strip or 25-TW strip (9 x 30 mm) can
be implemented.
Figure 4-36 MDFU-E - Layout and Dimensions (669.0 x 328.8 x 125.4 mm)
System side Line network
1
2
3
6
4
5
Jumpering
Channel
19
20
21
21 slots (9 x 30 mm)
328.8 mm
669.0 mm
Special built-in
comps.
2 x PFT1
or
