IP Telephony (Voice over IP)
10.6.4.3 Determining the Number of HG 1500 Boards Required
The intensity with which gateway connections and ISDN routing are used determines the num-
ber of HG 1500 boards necessary.
HG 1500 resources sufficient?
Using the following calculations you can determine if the available HG 1500 boards are suffi-
cient or if additional resources are required in the form of other HG 1500 boards.
Following tests, the performance level required by each HG 1500 function was determined, and
assigned a value in points. This is the performance level that must be supported by the board.
This calculation is based on the assumption that the following performance point totals are
available for each HG 1500 board:
HG 1500 board Total performance points per
board
HXGM3 980
HXGS3, HXGR3 780
STMI2 980
Note: Any available extension modules (PDM1, PDMX, etc.) are included in the additional per-
formance requirement in Table 10-11.
Table 10-11 Required Performance Level for Voice over IP
Function Resource require-
ment
(credit point)
Available extension
modules
Per PDM1 10
Signaling without
H.235 security (inde-
pendent of the WBM
setting "Enhanced B
Channels")
IP workpoint clients: system client, HFA cli-
ent, H.323 client (8 calls per hour)
0.51
IP networking channel (25 calls per hour) 3.2
Signaling with activat-
ed H.235 security (in-
dependent of the
WBM setting "En-
hanced B Channels")
IP workpoint clients: system client, HFA cli-
ent, H.323 client (8 calls per hour)
0.82
IP networking channel (25 calls per hour) 3.8
