Identifying System Power Requirements
P31003-H3550-S403-4-7620, 02/05
D-4 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
power_calc.fm
HiPath 3750 and HiPath 3700 Board Power Requirement
D.2 HiPath 3750 and HiPath 3700 Board Power Requirement
Table D-3 Nominal Output of the HiPath 3750 Power Supply Unit and HiPath 3700
Power Supply Unit Part Number Max. Nominal Output in W
5V –48V
UPSM S30122-K5950-A100
S30122-K5950-S100
S30122-K5959-S121 (for RSA
only)
60.0 166.0
>
You must check whether the total power requirement of the boards used and the
connected workpoint clients of a system cabinet exceeds the maximum possible
UPSM output. Section D.8 contains a sample calculation.
Table D-4 HiPath 3750 and HiPath 3700 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
BS3/1 S30807-H5482-X – 2.0
BS3/3 S30807-H5485-X – 3.0
CBCPR (including sub-
boards)
S30810-Q2936-X 8.5 –
GEE8 S30817-Q664-xxxx 1.0 –
HXGM3 S30810-Q2942-X 12.0 –
IVML8 S30122-X7380-X100 3.0 0.7
IVML24 S30122-X7380-X 5.0 1.0
PDM1 S30807-Q5692-X100 – 5.0
REAL S30807-Q5913-X 0.5 –
SLA8N S30810-Q2929-X200 1.5 1.5
SLA16N S30810-Q2929-X100 3.0 3.0
SLA24N S30810-Q2929-X 4.5 4.5
SLC16 S30810-Q2922-X 8.0 –
SLC16N S30810-Q2193-X100 5.0 –
SLMO8 S30810-Q2901-X100 0.7 –
SLMO24 S30810-Q2901-X 1.5 –
