Starting HiPath 3000 as a Gateway
P31003-H3550-S403-4-7620, 02/05
7-4 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
start_3g.fm
Starting HiPath 3700 as a Gateway
7.4 Starting HiPath 3700 as a Gateway
7.4.1 Prerequisites
Refer to Section 4.3.1 for information on the tools and resources needed to install the HiPath
3700 system.
7.4.2 Procedure for Installation and Startup
7
Warning
Only authorized service personnel should install and start up the system.
>
To ensure that IP addresses are not assigned more than once in the customer net-
work, you must ping each new IP address to be configured before each IP address
is assigned. If an IP address responds, then this address cannot be used again.
Table 7-2 HiPath 3700 as a Gateway - Procedure for System Installation and Startup
Step Activity (Remarks)
Installing HiPath 3700 (19-Inch Cabinet)
1. Selecting the Installation Site, page 4-128 (generally determined by the existing 19-
inch cabinet)
2. Unpacking the Components, page 4-128
3. Mounting the System Cabinet in the 19-Inch Cabinet, page 4-129
4. Mounting the Patch Panel in the 19-Inch Cabinet, page 4-133
5. Grounding the System, page 4-134
Checking the Grounding, page 4-136
6. Connecting the Cable to the Backplane, page 4-137
7. Connecting the Line Network to the Patch Panel, page 4-150
8. Loading the System Software and Installing Subboards on the CBCPR, page 4-151
9. Configuration notes, page 4-152 (cabinet(s) are already equipped with the boards)
We recommend that you check the board population using the configuration notes.
10. Making trunk connections
Refer to the following board descriptions for information:
● STMD8 - for S
0
trunk connection
● TMS2 (Not for U.S.) - for S
2M
trunk connection
● TMST1 (for U.S. only) - for T1 PRI trunk
To Next Page
