Siemens HiPath 3000 Service Manual

power_calc.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
D-5
Identifying System Power Requirements
HiPath 3750 and HiPath 3700 Board Power Requirement
STMD8 S30810-Q2558-X200 2.0 –
TIEL S30810-Q2520-X 1.0 –
TMAMF S30810-Q2587-A200 1.8
1
16.9
1
TMCAS S30810-Q2938-X Not Available
TMDID8 S30810-Q2507-X 1.4
1
23.8
1
TMGL8 S30810-Q2703-X 1.6
1
2.1
1
TML8W S30817-Q626-Axxx/Bxxx 1.0 –
TMST1 S30810-Q2920-X 3.0 –
TMS2 S30810-Q2915-X 3.0 –
1 Identified at a traffic flow of 0.8 Erlang
Table D-4 HiPath 3750 and HiPath 3700 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
